Tri Axle Stainless Steel Tanker Semi Trailer , Palm Oil / Crude Oil Tanker Trailer

Tri Axle Palm Oil Crude Fuel Petrol Oil Stainless Steel Tanker Semi Trailer

Factory direct supply tanker semi trailer is used to transport fuel, the capacity is from 30CBM to 60 CBM, the compartments are 1~6 compartments. Including steel tanker, stainless steel tanker trailer and aluminum tanker. The tank body is Q235/5mm steel, End plate Q235A/6mm steel sheet.

Trailer Photo show:

Stainless steel tanker trailers for carrying drink water, beer, milk with food grade 304 stainless steel.

Tri Axle Stainless Steel Tanker Semi Trailer , Palm Oil / Crude Oil Tanker Trailer

Producing Process

Trailer description

Main Dimensions
Tank Body
Shape	Optional(Round or Suare)
Dimension	12000mm2490mm3990mm(Exact size depend on the final design)
Tare Weight	About 8000Kg-12800Kg
Total Volume(m3)	25m3-60m3
Tanker Body Material	5mm or 6mm Stailess steel
End Plate	5mm or 6mm/Q235 Stailess steel
Manhole Cover	Stailess steel API manhole cover ,500mm
Bottom Volume	Stailess steel API Pneumatic Bottom Valve
Discharging Valve	Diameter is 3 or 4 inch
Compartments	Optional
Discharging Pipe	4” rubber hose,2 pcs,6m/each
Cat Walk	With (Common model or special design)
Chassis
Main Beams	Welding design or special design I beam ,connected by bolts and nuts Q345 carbon steel material
Axle	2 or 3 axles, BPW/FUWA/HUAJING brand
Landing Gear	JOSTD200T or China brand 28T
King Pin	JOST 2.00 OR 3.5 inch bolt-in king pin
Suspension	Mechanical suspension(Germany or American type)/air suspension
Leaf spring	90(w)mm13(Thickness0mm10 layer or 100mm12mm12/without
Pneumatic Braking System	WABCO RE 6 relay valve;Spring brake chamber;2 pieces of 45L air tanks.
Rim	9.00-22.5/8.00-20/8.5-20 China brand
Tire	12.00R22.5/315 80R22.5/11.00R20/12.00R20 Brand can be optional
ABS	Optional
Painting	Complete Chassis and blasting to clean rust,1 coat of anticorrosive prime,2 coats of final paint
Accessories	One standard tool lox
Shipping Terms	By bulk cargo ship, RORO or 40HQ container

30,000L-45,000L 3-axle Tank Semi-trailer
Feature:	Carry Fuel, Oil, Diesel, Drink water, Milk, Beer and other chemical liquid
Dimension(LWH):	1100025003700mm(30,000L) 1170025003750mm(40,000L) 1270025003750mm(50,000L) 1300025003750mm(60,000L) 1370025003750mm(70,000L)
Model	DRZ9350GRY
Material:	Carbon Steel	Stainless Steel	Aluminum
Compartment:	3-6
Capacity(kgs):	30,000L-65,000L
Tare weight(kgs):	10,000-11,000kgs	10,000-11,000kgs	6,000-7,000kgs
Kingpin	The world-famous JOST brand bolt-in/welded type 3.5”/2”
Landing gear	JOST brand two-speed manual operation 19”
Tire size	11.00R20,11R22.5,12R22.5,315/80R22.5,385/65R22.5
Rim size	8.2522.5,9.0022.5,11.75*22.5
Axle	Original BPW-12T/ FUWA-13T
Leafs spring	Germany type with 12pcs of leafs spring/ Fuwa brand with 8pcs of leafs spring/ Airbag suspension
Brake system	One unit WABCO RE 4 relay valve; four units T30/30 spring brake chamber; two units T30 spring brake chamber; two units reliable local brand 45L air tank; two units reliable local brand standard coppery air-connector.
Manhole:	Aluminum alloy ø500mm(20”) manhole with aluminum alloy cover; with breather valve;
Discharge Valve	Aluminum alloy discharge valve with cover
Foot Valve	Pneumatic control DN80 aluminum alloy foot valves
Pneumatic Control system	1set Pneumatic Control combined switch 1unit emergency switch
Discharge Hose	2 units 3”×6M factory PVC hose with quick coupling on both ends
Vapor Recovery & Overfill system	Optional
Fire Extinguisher Carrier	2 units at the left of rear of tanker, include 2 units 8kg dry powder type fire extinguisher inside
Electric system:	One unit of 24V 7-pin ISO standard socket; with brake light, turn light, reverse light, side light, reflector, fog light; one set of 6-pin standard cable
Prime & Topcoat painting	S.A.2.5standard sandblasting ;Zinc-rich & Polyurethane painting
We can build the trailers according to customer’s design and requirement

2 Loading and Packing

Warranty period and after sale service
2 axles 3 Axles Hydraulic Rear Dump Semi Trailer 30 ton 60 ton U shape
FAQ

· MOQ:1 SET
· Delivery date:25 workdays after we received deposit.
· Payment term:
1. 30% contract value as the deposit by T/T,70% contract value payoff before delivery after production finish.
2. 50% contract value as the deposit by T/T,50% contract value payoff before delivery after production finish
