Underground Storage Tank Customize Vertical Horizontal Carbon Steel Stainless lined PE 5-200T WhsApp:+8615271357675

Product Categories

Hubei Dong Runze Special Vehicle Equipment Co., Ltd

Contact Now

Underground Storage Tank Customize Vertical Horizontal Carbon Steel Stainless lined PE 5-200T WhsApp:+8615271357675

Ask Lasest Price
Brand Name :	Dong Run Ze
Model Number :	Steel lined PE
Certification :	C3
Price :	Negotiated at Weichat:King253725877
Payment Terms :	TT emial to <253725877@qq.com>
Supply Ability :	Ask us for Better Price <253725877@qq.com>
Delivery Time :	25 working days

Add to Cart

Product Details
Company Profile

Underground Storage Tank Customize Vertical Horizontal Carbon Steel Stainless lined PE 5-200T WhsApp:+8615271357675

High Steel Underground Oil Tank for Medical Wastewater Treatment Underground Double Structure Chemical Use FRP Oil Tank

high steel underground oil tank for Medical Wastewater Treatment
Volume of Tank	5 CBM (5 000 litters)
Filling Weight	19 90 kg
Tank Weight	1550 kg
Thickness of Shell	8 mm
Thickness of dish head	8 mm
Tank Diameter	1400 mm
External Dimensions ( length x width x height)	500015002600 mm
Material of Tank and Main Pressure Parts	Q345 R
Filling Medium	Liquefied Petroleum Gas ( Propane)
Design Pressure	1.77 MPa
Work Pressure	≤1.6 MPa
Work Temperature	≤50 °C
Corrosion Allowance	1 mm
Medium Density	420-590 kg / cbm
Certificate	SONCAP / ASME / ISO 9001 / ISO 14001 / OHSAS 18001
Manufacturing Standard	Pressure vessels, Supervision Regulation on cSafety Technology for Stationary Pressure Vessels of China, ASME standard
Safety valve of selection fitting	Safety valve , column magnetic reversible level meter, pressure gauge , thermometer , cut-off valve...

Underground Storage Tank Customize Vertical Horizontal Carbon Steel Stainless lined PE 5-200T WhsApp:+8615271357675

Underground double structure chemical use frp oil tank

Nominalvolume (m3)	Actual volume (m3)	Nominal diameter (mm)	Thickness (mm)	Cylinder length (mm)	Total length (mm)
20	20	2200	5/5	4500	5600
20	22.1	2200	6/6	5000	6100
30	30	2400	6/6	5750	6950
30	33.4	2400	8/8	6500	7700
40	40	2600	6/6	6600	7900
40	44.8	2600	8/8	7500	8800
50	50	2800	6/6	7100	8500
50	55.4	2800	8/8	8000	9400

Underground Storage Tank Customize Vertical Horizontal Carbon Steel Stainless lined PE 5-200T WhsApp:+8615271357675

Underground Tank of Oil with 30000liters -100000L Capacity Underground tank with 30000liters capacity

SPECIFICATIONS FOR FUEL TANKER UNDER THE GROUND
Tanker	Inner layer	Material/mm	Q235b/8MM
	Outer Layer	Material/mm	Fiber glass/4mm
	Interlayer	Mm	0.1
Design Main Specifications	Design pressure	Mpa	0.08
	Design temperature	°	<=50
	Design lifespan	Year	30
Dimension	Size	mm	650026002600
	Shell end	mm	10
	Manhole	pc/dia	2/600mm

Underground Storage Tank Customize Vertical Horizontal Carbon Steel Stainless lined PE 5-200T WhsApp:+8615271357675

Underground Gasoline Fuel Oil Storage Tank

parameter

Large size UL underground gasoline fuel oil storage tank	Item	Specfication (m3)	Diameter (mm)	Length (mm)	Thick of cylinder (mm)	Thickness of end(mm)	Manhole	Inner carriage
	1	20	2400	4970	6	8	1	2
	2	30	2500	6870	6	8	1	3
	3	40	2600	8469	6	8	1	3
	4	50	2800	9128	6	8	1	3
	5	80	3000	12723	6	10	2	5
	6	100	3200	13978	6	10	2	5
Note	We can supply customized size gas storage tank

Underground Storage Tank Customize Vertical Horizontal Carbon Steel Stainless lined PE 5-200T WhsApp:+8615271357675

Steel Lined LLDPE Acid Chemical Tank for Dilute Sulfuric Acid H2SO4 HF HCL Acid Storage 5-100T WhatsApp:+8615271357675

PE Lined Acid Chemical Tank Chemical Reactor Tank Acid Tower (10m3 -20 M3Acid Storage Tank )

Vertical Steel Lined LLDPE Tank 3000gal -35000 Gallon Hydrochloric Acid Storage Tank 1kl-135kl

FOB Price: US $3,000-35,000 / Piece

Min. Order: 1 Piece

HCl Naclo Storage Dosing Tanks (Carbon Steel Tank Lined LLDPE corrosion resistance Sodium Hypochlorite, Hydrochloric Acid) Vertical 5 -50kl Measuring Tank

FOB Price: US $5,000-15,000 / Piece

Min. Order: 1 Piece

125 -150 Cbm Vertical Steel Lined Plastic (LLDPE) Storage Tank for HCl (max 35%) , Naoh (max 50%) , Naclo (max 10%) , H2so4 Chemical Liquid Corrosion Resistance

FOB Price: US $15,000-35,000 / Piece

Min. Order: 1 Piece

Chemical Storage Tank Customize 1000L -25000L (Vertical / Horizontal Acid Storage Tank Steel Lined LLDPE)

FOB Price: US $5,000-15,000 / Piece

Min. Order: 1 Piece

Customize Checmial Acid Storage Tank 100t (Steel Lined LLDPE Tank For Storage Bleach, Hydrochloric Acid, Ferric Chloride, Oilfield Chemicals, Corrosive Wastes)

FOB Price: US $5,000-35,000 / Piece

Min. Order: 1 Piece

Reactor Tank (Chemical Storage Reactor Tank Carbon Steel Inner lining LLDPE, Stainless Steel, PE) 1-25m3 Customize Mixer Bar

FOB Price: US $5,000-35,000 / Piece

Min. Order: 1 Piece

PTFE / F4 Lined Butterfly Valve (Ball Valves CS/F46, D371F4-16C, Pneumatic Q641F46-16C) for Chemical Acid Tank

FOB Price: US $50-500 / Piece

Min. Order: 1 Piece

13200 Gallon Hydrochloric Acid Storage PE Tank (Vertical/Horizontal LLDPE Tank Sodium Hypochlorite, HCl Acid 10566Gal, 7925Gal, 5283Gal, 3962Gal, 2641Gal)

FOB Price: US $3,000-10,000 / Piece

Min. Order: 1 Piece
